M200

https://ctek-batterychargers.co.za/wp-content/uploads/2017/11/CTX_BATTERY_SENSE-Productsheet-low-UK-EN.pdf

The perfect charger for all boat owners

Quiet and flexible

The M200 charges a wide range of marine batteries quickly and effectively.

The M200 is the perfect 15A battery charger for all boat owners. It has a range of functions, including a Recond mode for reconditioning deeply discharged Wet and Ca/Ca batteries, and a temperature sensor which optimises the charge if the temperature deviates from +25ºC. It also has a special Silent Night mode which reduces the noise of the fan by lowering the output power during periods of low energy consumption, such as at night. The M200 comes with a long 4m cable with eyelets for easy installation on your boat.

Enquire
Category:

Description

  • Special Features

    Charges batteries from 28Ah up to 300Ah and maintains larger batteries up to 500Ah

    Recond program for deeply discharged batteries
    Analysis step to check if battery can hold its charge
    Temperature compensated
    Short circuit proof

    • Compact tough design
    • Silent Night mode
    • IP44 rated, making it suitable for outdoor use
    • Safe spark free operation
    • 5-year warranty

Spec Sheet

M200-Productsheet-low-UK-EN

User Manuals



Technical Information

Input

220–240VAC, 50–60Hz, 2.9A max

Output

14.4V, 15A max

Back current drain*

Corresponding to less than 2Ah/month

Ambient temperature

-20˚C to +50˚C

Battery types

All types of lead-acid batteries, 12V, WET, MF, AGM, GEL

Battery capacity

28–500Ah

Warranty

5 years

Insulation class

IP44
